SANTAFIXIE RAVAL SINGLESPEED / FIXEDGEAR COMPLETE BIKE

  • Rahmen und Gabel: doppelt konifiziertes 6061 Aluminium
  • Kurbelgarnitur: 44 Zähne, 165 mm Länge
  • Innenlager: 68 / 107 mm, abgedichtete Kugellager
  • Pedale: BMX FK Plattformpedale
  • Felgen: Aluminium, 30 mm Profil, Santafixie
  • Reifen: Kenda K152 schwarz/braun / Chaoyang Mini Shark. Anti-Pannen, 700C x 25 mm
  • Naben: Flip-Flop-Nabe am Hinterrad
  • Ritzel: Fixed- und Freilaufritzel mit jeweils 16 Zähnen enthalten
  • Lenker: Riser Bar
  • Vorbau: Ahead-Vorbau
  • Bremsen: Radius Felgenbremse für Vorder- und Hinterrad
  • Sattel: Sntfx x Essax Adrenaline RMX
  • Sattelstützmaß: 27,2 mm
  • Gewicht: 9,5 kg (Größe 52)

MANKIND SUNCHASER BMX COMPLETE BIKE SOFORT LIEFERBAR LIMITED STOCK AVAILABLE

The Mankind Sunchaser Bike is designed with a classic BMX look and feel in mind and so here it is, a true archetype BMX Bike, which is a great allround machine, especially suitable for trails and bowls riding.

FRAME. 100% Chromoly Frame – TT & DT Gusset
TOP TUBE. 21.0”
CHAIN STAY. 13.75”

HEAD TUBE. 74.5°

SEAT TUBE. 71°

BB HEIGHT. 11.5”

STAND OVER. 9.0”

BRAKE MOUNTS. Removable Brake Mounts & Cable Stopper

FORK. 100% Chromoly – 1-PC Steerer, Tapered Legs, 28mm offset

BARS. 100% Chromoly – 9.2” Rise, Back: 12°/ Up: 2°, Width: 29.0”

GRIPS. MANKIND Control Grips

BAR ENDS. MANKIND Nylon

STEM. MANKIND Sunchaser Stem – 50mm reach

HEADSET. MANKIND Control Sealed Integrated

BRAKE. Alloy U-brake

BRAKE. LEVER Alloy Lever – 2-Finger Design – Hinged

REAR HUB.MANKIND Control Cassette Hub – Sealed – 14mm axle – 9t

FRONT HUB. MANKIND Control Front Hub – Sealed – Female Axle
SPROCKET. MANKIND Sunchaser Alloy 28t

CRANKS. Chromoly – 8 Spline – 3-Piece – 170mm – 19mm

BOTTOM BRACKET. Mid BB Sealed – 19mm

CHAIN. P121 Halflink

PEDALS. MANKIND Control Plastic

FRONT RIM. Alloy – Double Wall 36H
REAR RIM.  Alloy – Double Wall 36H

SPOKES. Steel Spokes – 14mm nipples – black

FRONT TIRE.SHADOW Strada Nuova LP 2.30”

REAR TIRE. SHADOW Strada Nuova LP 2.30”

SEAT. MANKIND Sunchaser Pivotal Seat

SEAT POST. Pivotal Seatpost Alloy

SEAT POST CLAMP. Integrated

WEIGHT. 11,90 kg
